CMMG M4F22 Rifle By Falcon Design
The stock information shown above is very accurate and updated dynamically. In stock items are shipped the same day when ordered before 2pm, or can be collected after ordering. Warehouse items will arrive with us in the timescale shown. Collection is by appointment only and must be booked in advance. Our phone lines can get extremely busy and email is the most efficient way to communicate with us!
Falcon Design build • CMMG Mk4 architecture • .22 LR
A proper AR-platform rimfire, built from named components.
The CMMG M4F22 Rifle by Falcon Design is assembled around CMMG’s dedicated .22 LR system rather than dressed up to resemble an AR. Billet and forged aluminium receivers, a stainless EBF barrel, slim CMMG EML handguard and premium TriggerTech fire-control group give it the handling, controls and modularity expected from a serious AR-pattern rifle.
At this price point, we think it is the benchmark complete .22 LR AR build: the value is in the component list, with genuinely useful ambidextrous controls, a crisp 3.5 lb trigger and proven Magpul furniture included from the start.
Choose your build
12″ / EML11
or 16″ / EML15
Finish: Armor Black or Tungsten Cerakote
Stock: Six-position Magpul MOE
Magazine: One CMMG 25-round .22 LR magazine
Calibre
.22 LR
Operating system
Dedicated CMMG blowback
Barrel
12″ or 16″ stainless
Trigger
3.5 lb single-stage
Assembled size and weight
The adjustable stock provides 3.3″ of travel. Figures below are practical assembled estimates with the stock fully collapsed and fully extended, unloaded with the supplied empty magazine, before sights, optic or other accessories.
| Variant | Handguard | Approx. overall length | Approx. weight | Finish options |
|---|---|---|---|---|
| 12″ barrel | CMMG EML11 | 27.3–30.6″ 693–777 mm | 5.7 lb 2.6 kg | Armor Black / Tungsten |
| 16″ barrel | CMMG EML15 | 31.3–34.6″ 795–879 mm | 6.2 lb 2.8 kg | Armor Black / Tungsten |
Dimensions and weights are research-based assembled estimates from published component specifications and comparable Mk4-pattern builds. Small production and measuring variations are normal. The transport case is not included in rifle weight.
The core build
Receivers and finish
The CMMG Mk4 upper is billet 6061-T6 aluminium with a ZEROED polymer dust cover and enlarged ejection port. It pairs with a forged 7075-T6 Mk4 lower. Upper, lower and handguard are matched in your choice of Armor Black or Tungsten Cerakote.
Dedicated rimfire action
A stainless EBF AR15-pattern .22 LR barrel is matched to the CMMG dedicated .22 LR bolt group. This is a purpose-built blowback system with the correct rimfire chamber and bolt geometry, delivering authentic AR controls without relying on a centre-fire chamber adaptor.
Slim free-float front end
The 12″ rifle uses an 11″ EML11; the 16″ uses a 15″ EML15. Both are aircraft-grade 6061-T6 aluminium with a 1.3″ internal / 1.5″ external diameter, M-LOK slots at 3, 6 and 9 o’clock, and a Picatinny/M-LOK hybrid top rail. Barrel nut, retention key and fixings are part of the CMMG handguard kit.
TriggerTech Duty fire control
The fitted TriggerTech Duty AR15 is the curved, fixed 3.5 lb single-stage version. Its cassette design provides a zero-creep break, 0.060″ overtravel and a short, positive 0.070″ reset, with full hammer-strike force and standard 0.154″ pin compatibility.
Controls that work from either shoulder
- CMMG ZEROED ambidextrous safety, configurable for a short 60° or conventional 90° throw.
- CMMG ambidextrous magazine catch with standard right-side button and left-side paddle.
- CMMG ZEROED .22 LR ambidextrous charging handle with a filled, reinforced channel designed to prevent spent rimfire cases entering a standard AR charging-handle channel.
- CATCH22 V1 bolt catch for familiar manual bolt-hold-open function. The supplied CMMG magazine follower does not automatically actuate this catch; engage it manually after removing the magazine.
Proven Magpul furniture
- Magpul MOE Carbine Stock: 10.3–13.6″ length of pull, 3.3″ adjustment range, 8.4 oz, shielded release latch and removable 0.30″ rubber butt-pad.
- CMMG six-position mil-spec receiver extension kit with aluminium buffer tube, end plate, castle nut, spring and buffer.
- Magpul MOE AR15/M4 grip: 25° angle, 4.0″ height, 1.2″ maximum width and 2.8 oz with hardware; textured reinforced polymer with internal storage-core capability.
Complete build specification
Upper assembly
- CMMG Mk4 billet upper receiver assembly with ZEROED dust cover
- CMMG dedicated .22 LR bolt group
- EBF stainless .22 LR barrel: 12″ or 16″
- CMMG EML11 or EML15 handguard kit, matched to barrel length
- CMMG ZEROED ambidextrous .22 LR charging handle
Lower assembly
- CMMG Mk4 forged lower receiver
- TriggerTech Duty curved 3.5 lb single-stage trigger
- CMMG ZEROED 60°/90° ambidextrous safety
- CMMG ambidextrous magazine catch
- CATCH22 V1 bolt catch
- Falcon anti-walk trigger pins
Furniture and small parts
- Magpul MOE six-position carbine stock
- Magpul MOE AR15/M4 grip
- CMMG receiver extension/buffer kit
- UK-designed and manufactured Falcon MA-12 polymer trigger guard
- Falcon lower-parts set: Tuffride-coated 303 stainless pins and components with M3 steel springs
- Bolt-catch roll pin, spring and buffer; buffer retainer and spring; pivot/takedown pins, detents and springs; selector detent and selector spring
Supplied with the rifle
- One CMMG Mk4/AR15 25-round .22 LR magazine
- Solognac 104 hard transport case: impact-resistant polypropylene shell, 10 mm foam, four clips and two 7 mm padlock points
- Final assembly, function check and proof process
Sights, optic, mounts and other accessories are not included unless explicitly shown as part of a selected package.
Which version?
Choose the 12″ for the shortest, quickest-handling configuration and the compact EML11 front end. Choose the 16″ for a longer sighting plane, more support-hand and accessory space, and the full-length EML15 profile. Armor Black is understated and traditional; Tungsten gives the same component specification with a more distinctive contrast against the black furniture and controls.
Whichever version you choose, the important parts remain the same: a dedicated CMMG rimfire action, premium TriggerTech trigger, fully considered ambidextrous controls and familiar, replaceable AR-pattern furniture. It is a complete rifle that does not need a list of immediate upgrades to feel finished.
