CALIBRE: 6.5 Creedmoor (short action)

WEIGHT: 5.94 kg (13.1 lbs) - With magazine, no scope and 24” barrel.

LENGTH: 1086 mm (42.75 ins)  - With butt pad not extended and 24” barrel.



7075 billet aluminium chassis, fixed buttstock. Removable interface for folding hinge kit available as an accessory.

Target adjustable butt pad

Adjustable length of pull: min. 321 mm (12.6”) with a total range of 55 mm (2.15”) in 5.5 mm (0.215”) increments. Additional butt spacers can also be used.


Height adjustable range: 22 mm (0.86”) in 5.5 mm (0.215”) increments.

Pistol grip

Designed to accept most AR-style pistol grip.


Standard AT/AX short action with 20MOA low action rail, bolted to the chassis.


AI patented barrel removal/change system.


6 lug, 60° bolt lift with leaf spring extractor and 1.6mm firing pin.


Three-position safety on bolt shroud.


AI USA / XTSP competition trigger. Adjustable pull weight: 0.68 - 1.25 kg (1.5 - 2.75 lb) heavy spring.


1 x detachable 10-round double-stack magazine P/N AI-6677 - can also be top-loaded through the rifle ejection port.  Left side magazine port cut out for ease of magazine insertion plus new slim profile mag catch for ambidextrous extraction.


Low profile single plane forend with integral RRS spec. rail interface, KeySlotTM mounting system and machined barrier support Length: 445 mm (17.5”).

KeySlotTM mounting system

Featured on the forend and right-hand side of the magazine aperture, AI’s patented KeySlotTM mounting system allows rapid and secure attachment of rails or other accessories.


416 stainless steel, 6 groove, 1:8 twist 24” (610 mm) 6.5 Creedmoor, ‘competition’ grade heavy profile cut-rifled barrel with 5/8 x 24 UNEF threaded muzzle with thread protector included. Manufactured in England by AI UK (base rifle does not include muzzle brake).


Short and long forend bridges

Easily attached to the forend interface, a bridge adds extra space for KeySlotTM rails and accessories whilst protecting the barrel.

Folding stock hinge

Replaces interface to create a folding stock.


Internal, external and stackable .227 kg (1⁄2 lb) weights to reduce recoil and increase width for increased contact/stability on a bag.
