Beretta DT10 Trident Trap 12G Parts Guide

Exploded diagram, Beretta codes and linked spare parts for Beretta DT10 Trident Trap 12G.

Exploded diagram

Beretta DT10 Trident Trap 12G exploded parts diagram
PositionBeretta CodeStockDescription & Product Link
002
C55673
C55674
C55675
Warehouse Stock
Out Of Stock
Out Of Stock
White Bradley Type Bead Medium
Small Red Front Bead Sight
Large Red Bead Sight
002A
C54550
In Stock
Mid Bead - Small
003
C90421
In Stock
Ejector Spring 12G
004
C92208
In Stock
Ejector Plunger 12G
005
E59180
In Stock
Bottom Ejector Right Hand
006
E59179
Warehouse Stock
Top Ejector Left Hand
007
C55465
Warehouse Stock
Barrel Shoulder Right Hand
008
C55475
Warehouse Stock
Barrel Shoulder Left Hand
009
C95053
Warehouse Stock
Barrel Shoulder Screw
012
C59295
C59296
C84412
C84414
C84416
C84422
C84423
C86924
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
FOREND BEAVERTAIL CLASS 3 GA 12 OIL FINISH DT10 SPORTING DT10 TRAP
FOREND SCHNABEL SPORTING OIL FINISH CLASS 3 DT10 SPORTING DT10 TRAP GA 12
SET STOCK LEFT HAND LH SX 32/42 CLASS 3 OIL FINISH AND FOREND BEAVERTAIL - DT10 TRAP GA 12
SET STOCK RIGHT HAND RH DX 32/42 CLASS 3 OIL FINISH AND FOREND BEAVERTAIL - DT10 TRAP GA 12
SET STOCK ADJUSTABLE BFAST LEFT HAND LH SX CLASS 3 OIL FINISH AND FOREND BEAVERTAIL - DT10 TRAP GA 12
SET STOCK RIGHT HAND RH DX 34/44 CLASS 3 OIL FINISH AND FOREND BEAVERTAIL - DT10 TRAP GA 12
SET STOCK LEFT HAND LH SX 34/44 CLASS 3 OIL FINISH AND FOREND BEAVERTAIL - DT10 TRAP GA 12
SET STOCK PISTOL GRIP LEFT HAND LH SX 34/44 OIL FINISH CLASS 3 AND FOREND BEAVERTAIL DT10 TRAP
013
C59192
C59194
C59195
Warehouse Stock
Warehouse Stock
Warehouse Stock
Fore-end Iron Insert No. 1
Fore-end Iron Insert No. 2
Fore-end Iron Insert No. 3
013A
C97067
Not Available
ELASTIC PIN 2X16 DT11 DT10
014
C59191
Not Available
FORE-END IRON
015
C59201
Warehouse Stock
Forend Screw
016
C59240
Warehouse Stock
Forend Washer
017
C53777
Warehouse Stock
Fore-End Catch Spring
018
C53313
Not Available
FORE-END IRON CATCH
019
C92219
Warehouse Stock
Forend Catch Pin
020
C97060
Warehouse Stock
Forend Iron Catch Pin Selector Pawl Pin
021
C59182
Warehouse Stock
Top Ejector Trip, Left-hand
022
C59181
Warehouse Stock
Bottom Ejector Trip, Right-hand
023
C59199
Not Available
FOREND LEVER PIN DT11 BLACK
024
C95180
Not Available
FOREND IRON LEVER PIN DT11 DT10 ASE90 ASE GOLD
025
C92231
Warehouse Stock
Ejector Trip Plunger
026
C90282
Warehouse Stock
Ejector Trip Spring
028
C59198
C59671
Warehouse Stock
Not Available
Black Hinge Disc
HINGE PIN STANDARD GLOSSY FOR DT11
029
C50048
Warehouse Stock
Cocking Rod
030
C95058
Warehouse Stock
Cocking Rod Retaining Screw
031
C53114
Warehouse Stock
Top Cocking Dog Left Hand
032
C53113
Warehouse Stock
Bottom Cocking Dog Right Hand
033
C92232
Warehouse Stock
Cocking Dog Pin
034
C54199
Warehouse Stock
Cocking Dog Spring Left Hand
035
C54200
Warehouse Stock
Cocking Dog Spring Right Hand
036
C57464
Warehouse Stock
Top Firing Pin
037
C57258
Warehouse Stock
Bottom Firing Pin
038
C92233
Warehouse Stock
Firing Pin Retaining Pin
039
C90311
Warehouse Stock
Firing Pin Spring
041
C55682
Warehouse Stock
Top Lever Trip
042
C90136
Warehouse Stock
Top Lever Trip Spring
044
C90133
Warehouse Stock
Top Lever Spring
045
C92149
Not Available
TOP LEVER SPRING PIN S02 ASE 90 ASE GOLD DT10 TRIDENT DT11
047
C95258
Not Available
SCREW
048
C97103
Warehouse Stock
Top Lever Screw Washer
049
C52172
Warehouse Stock
Top Lever Screw Nut
050
C59233
Not Available
SPRING
051
C59205
Warehouse Stock
Trigger Release Bolt
052
C92250
Not Available
PIN
053
C56146
Warehouse Stock
Stock Bolt Washer
054
C56147
Warehouse Stock
Stock Bolt Washer Small
055
C97079
Warehouse Stock
Stock Bolt Spring Washer
056
C59237
Not Available
FIRING PIN CATCH LEVER DT11
057
C92251
Not Available
PIN
058
C55083
Not Available
TRIGGER PLATE BOLT DT11
059
C90352
Warehouse Stock
Trigger Mechanism Locking Bolt Spring
060
C95059
Warehouse Stock
Safety Spring Screw
061
C59234
Warehouse Stock
Safety Spring
063
C92243
Warehouse Stock
Safety Catch Spring Pin
072
C54986
Warehouse Stock
Action Stock Bolt Receiver
073
C92253
Not Available
BLOCK SCREW PIN - DT11 GA 12
074
C59775
Warehouse Stock
Bottom Hammer, Right-hand
075
C59774
Warehouse Stock
Top Hammer, Left-hand
076
C54937
Warehouse Stock
Hammer Pin
077
C59154
Warehouse Stock
Mainspring
078
C58207
Not Available
MOLDING 486
079
C92237
Not Available
TRIGGER PIN - ASE 90 - ASE GOLD - DT10 TRIDENT GA 12
080
C53778
Warehouse Stock
Trap Non-selective Sear Spring 6mm
081
C53782
Not Available
SEAR SPRING 0.6 12 GA ASE90 / ASE GOLD / DT10 TRIDENT
082
C92235
Out Of Stock
Sear Spring Pin
083
C59717
Warehouse Stock
Bottom Right-hand Non-selective Sear
084
C59772
Warehouse Stock
Top Left-hand Non-selective Sear
087
C53367
Warehouse Stock
Inertia Block, Non-selective
089
C62410
In Stock
B-Fast Adjustable Stock Allen Key
090
C92241
Not Available
PIN
091
C90300
Warehouse Stock
Inertia Block Spring
092
C92110
Warehouse Stock
Inertia Block Spring Plunger
093
C97191
Not Available
ELASTIC PIN - DT11 GA 12
094
C59242
Not Available
SUPPORT FOR ADJUSTABLE TRIGGER - DT10 GA 12
095
C90284
Warehouse Stock
Trigger Spring
096
C56005
Warehouse Stock
Trigger Spring Plunger
097
C95287
Warehouse Stock
Adjustable Trigger Screw
098
C97148
Warehouse Stock
Adjustable Trigger Ball
099
C59241
C59260
C81183
Warehouse Stock
Not Available
Not Available
Adjustable Trigger, Straight
TRIGGER
LH LEFT HAND ADJUSTABLE TRIGGER - DT10 GA 12
100
C83388
Not Available
MEMORY SYSTEM SET FOR 682 AND DT10
101
C83389
Not Available
MEMORY SYSTEM SET FOR 682 AND DT10
102
C59243
Not Available
TRIGGER PLATE - DT10 TRIDENT GA 12
103
C92234
Warehouse Stock
Mainspring Retaining Pin
104
C90326
Not Available
SPRING
105
C97037
Warehouse Stock
Inertia Block Roll Pin (Large)
107
C81228
C81229
C81230
C81232
C84794
C84796
C84798
C85530
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
STOCK PISTOL GRIP RIGHT HAND RH DX 34/44 CLASS 3 OIL FINISH - DT10 TRAP GA 12
STOCK LEFT HAND LH SX 34/44 CLASS 3 OIL FINISH - DT10 TRAP CAL 12
STOCK ADJUSTABLE LEFT HAND LH SX CLASS 3 OIL FINISH - DT10 TRAP CAL 12
STOCK PISTOL GRIP MONTECARLO ADJUSTABLE B-FAST RIGHT HAND RH DX CLASS 3 OIL FINISH - DT10 TRAP CAL 12
STOCK RIGHT HAND RH DX 32/42 CLASS 3 OIL FINISH - DT10 TRAP CAL 12
STOCK LEFT HAND LH SX 32/42 CLASS 3 OIL FINISH - DT10 TRAP GA 12 - ASE TRAP GA 12
STOCK RIGHT HAND RH DX 34/44 CLASS 3 OIL FINISH - DT10 TRAP CAL 12 - ASE GOLD TRAP
STOCK PISTOL 34/44 GRIP LEFT HAND LH SX OIL FINISH CLASS 3 - DT10 TRAP CAL 12
109
C95192
In Stock
Pad Screw - 40mm
110
C61280
Warehouse Stock
Round Handle Stock Key
113
C97018
Warehouse Stock
Trigger Release Ball
114
C95225
Warehouse Stock
Stock Bolt Standard
115
C53949
Not Available
BUSH STOCK KEY GUIDE 12 GA S682
